| 构件部分 Component parts | 材料名称 Name of material | 规格型号 Specification (mm) | 备注 Note |
|---|---|---|---|
| 基本尺寸 Basic dimension | 外部尺寸 Outer dimensions | 5900*2480*2510 | - |
| 内部尺寸 Inside dimensions | 5740*2360*2390 | - | |
| 折叠尺寸 Folded Size | 5900*2480*360 | - | |
| 底部框架 Bottom frame | Q235方管 Q235 square tube | 60*140*1.3 | - |
| Q235方管 Q235 square tube | 60*80*1.3 | - | |
| Q235方管 Q235 square tube | 40*40*1.2 | - | |
| 顶部框架 Top frame | Q235方管 Q235 square tube | 40*80*1.3 | 异型方管 Shaped square tube |
| Q235方管 Q235 square tube | 60*60*1.3 | - | |
| Q235方管 Q235 square tube | 40*40*1.2 | - | |
| Q235方管 Q235 square tube | 20*20*1.2 | - | |
| 3m/6m侧立面（异型钢） 3m/6m side elevation (profiled steel) | Q235方管 Q235 square tube | 50*70*1.2 | 异型方管 Shaped square tube |
| 板材 Sheets | 地板 Floor | 2855*1177*15 | 防火玻镁板 Fireproof glass-magnesium board |
| 防水顶板 Waterproof roof | 2520*1000*0.35 | 压型彩钢板 Pressure moulded colour steel plate | |
| 吊顶板 Suspended ceiling plate | 2340*1000*0.25 | 压型彩钢板 Pressure moulded colour steel plate | |
| 彩钢板 Colour steel plate | 1150*65/50*0.25 | 50mm/65mm厚EPS复合板/岩棉板 50mm/65mm thick EPS composite panel/rock wool panel | |
| EPS | 12kg/m³ | 保温防火 Insulation and fireproof | |
| 玄武岩棉 Basalt cotton | 60kg/m³ | 保温防火棉 Insulation and fireproof cotton | |
| 配件 Accessory | 防盗门 Entrance door (for apartment) | 970*1970 | 钢制门 Steel door |
| 塑钢窗 Moulded window | 970*970 | 单玻、纱窗、护栏 Single-glazed, screened windows, guardrails | |
| 电路 Electrical equipment | 电器布线，严格按照防潮规范安装。根据电路工程规范连接电路，室内：进线4㎡国标软铜线插座进线2.5㎡ Electrical wiring, installed in strict accordance with the norms of moisture protection. Connect circuits according to circuit engineering specifications, indoor: incoming 4mm² national standard soft copper wire socket incoming 2.5mm² | ||
| 电灯控制开关 Light control switch | 3个插座，面板开关一个 3 sockets, one panel switch | ||
| 灯 Light | 灯座一个，节能灯一个 One lamp holder, one energy-saving lamp | ||
| 断路器 Interrupter | 高分段小型断路器，配漏电开关 High sectional miniature circuit breakers with earth leakage switches | ||
